Stainless steel / brass fillable pressure gauge

Designed for outdoor and high humidity installations, this glycerine fillable pressure gauge features a stainless steel case and brass connection to provide waterproof and corrosion resistant properties. Strong, sturdy, and built with Brannan’s signature quality and accuracy, this stainless steel pressure gauge can be filled with glycerine to protect the instrument from pulsations and pressure peaks, as well as to keep the needle steady. With multiple connection types available, and the option of panel mounting, this is a quality, reliable pressure gauge, ideal for HVAC, machine and apparatus construction, and high humidity applications.

Product Features

Fillable pressure gauge with stainless steel waterproof and corrosion resistant case and brass connection
Glycerine filling available
Front or back flange available for panel mounting
Brannan quality and accuracy
For outdoor and high humidity installations
Custom printed logo available on this product - please contact us to enquire

Specification

Ideal with HVAC installations, machine and apparatus constructions and high humidity installations
Wide range of associated accessories available
50mm, 63mm and 100mm
Accuracy class 1.6
Ranges from -1 to 0 bar & psi, through to 0 to 600 bar & psi
¼” BSP brass bottom entry (50mm), 1/4" BSP brass bottom or centre back entry (63mm) or 1/2" BSP brass bottom or lower back entry
Traceable calibration available
100mm diameter cast Aluminium case, black figures, forged brass sockets
